Scarlett 4i4
The original music maker's 4-in, 4-out interface

Description
Scarlett 4i4 is the complete compact studio hub for all your instruments. Perfect for multi-instrumentalists and collaborators, 4i4 is loaded with I/O for everything. Two of our most detailed ultra-low-noise mic preamps. Hi-Z, line and MIDI connections for your keys, guitars, synths, grooveboxes and controllers. With 4i4 your headphones, monitors, and line outs each get their own mix, so you can match the studio setup to the session.
Air mode, with Presence and Harmonic Drive, gives you that big console sound wherever you record. Auto Gain and Clip Safe make sure you'll never need to worry about your levels. And the Hitmaker Expansion software bundle includes all the tools you need to record, produce and release your tracks.

Two of our most detailed, ultra-low-noise preamps.
Plug into 4i4’s 4th-Generation remote-controlled preamps – Scarlett’s clearest and most detailed ever, with a huge 69dB gain range to get the best from every mic.

Auto Gain and Clip Safe.Let 4i4 handle your levels.
Auto Gain sets your levels and Clip Safe keeps them in the sweet spot, automatically tweaking the gain if you’re in danger of clipping. You'll never lose a take again.

Specifications in detail
Overview
Number of Microphone Preamps2
Phantom PowerYes
Instrument Inputs2
Line Inputs4
Air ModeYes
Auto GainYes
Clip SafeYes
Line Outputs4
Headphone Outputs1
LoopbackYes
MIDIYes
ConnectivityUSB Type-C
ProtocolUSB 2.0
Form FactorDesktop
Simultaneous I/O6 x 6 (including Loopback inputs)
A/D Resolution24-bit/192 kHz
Bus PoweredYes (1.5A)
Supported sample rates
44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz
Microphone inputs
Frequency Response20-20kHz ± 0.06dB
Dynamic Range116dB (A-Weighted)
THD+N-100dB @ 8dB gain
Noise EIN-127dBu (A-Weighted)
Maximum Input Level16dBu
Gain Range69dB
Impedance3kΩ
Variable Line inputs
Frequency Response20-20kHz ± 0.05dB
Dynamic Range115.5dB (A-Weighted)
THD+N-100dB @ 8dB gain
Maximum Input Level22dBu
Gain Range69dB
Impedance60kΩ
Fixed Line inputs
Frequency Response20-20kHz ± 0.02dB
Dynamic Range115.5dB (A-Weighted)
THD+N-105dB
Maximum Input Level22dBu
Impedance60kΩ
Instrument inputs
Frequency Response20-20kHz ± 0.15dB
Dynamic Range113dB (A-Weighted)
THD+N-80dB @ minimum gain
Maximum Input Level12dBu
Gain Range62dB
Impedance1MΩ
Line outputs (Balanced)
Frequency Response20-20kHz ± 0.02dB
Dynamic Range120dB
THD+N-112dB
Maximum Output Level16dBu
Impedance100Ω
Headphone outputs
Frequency Response20-20kHz ± 0.1dB @ 33Ω / 300Ω
Dynamic Range112dB @ 33Ω
115dB @ 300ΩTHD+N-99dB @ 33Ω
-108dB @ 300ΩMaximum Output Level5dBu into 33Ω
11dBu into 300ΩMaximum Output Power57mW into 33Ω
27mW into 300ΩImpedance11Ω
Analogue to Digital Converter
THD+N-110dB
Dynamic Range120dB
Digital to Analogue Converter
THD+N-115dB
Dynamic Range130dB (A-Weighted)
Power
USB1.5A
External (Optional)7.5W
